Simplift – Elegant & Versatile Homelift
The Simplift is an elegant and versatile homelift with a travel height of up to 15 meters. This electric screw-driven lift features modern MRL technology, making it ideal for both indoor and outdoor use. Its cabin is highly adaptable and customizable, perfect for homes and businesses alike.
Key Features
- 🔧 Electric screw-driven mechanism with MRL technology
- 🏠 Suitable for both indoor and outdoor installations
- 📏 Travel height up to 15 meters
- 🎨 Customizable cabin dimensions and finishes
- 🔇 Quiet operation with minimal maintenance
- 🛠️ No need for a machine room or pit
- ✅ Compliant with D.M. 2006/42/CE and EN81.41:2010 standards
Technical Specifications
| Drive System | Screw-driven electric motor |
|---|---|
| Usage | Indoor and Outdoor |
| Maximum Travel | 15 meters / 6 Stops |
| Load Capacity | Up to 400 kg |
| Speed | 0.15 m/s |
| Car Dimensions | Min. 600x1000 - Max. 1100x1400 / 1200x1250 |
| Pit Requirement | 100mm |
| Power Supply | Single Phase, 230V AC |
| Installation | Indoor and Outdoor - In masonry shaft or self-supporting metal structure |
| Compliance | D.M. 2006/42/CE – EN81.41:2010 |
Image Gallery
